HCA-60 PLAY
2x30W Mini Digital Amplifier with USB & BT
Description
HCA-60 PLAY delivers 2x30W @ 4-16ohm in a very compact design. The Class-D amplification stage ensures high efficiency, low thermal dissipation and maximum reliability.
The USB and BT player with remote control allow audio contents reproduction and makes this amplifier easy to use for any user in installations such as hotels, shops, offices, home, and much more.
HCA-60 PLAY delivers 2x30W @ 4-16ohm in a very compact design. The Class-D amplification stage ensures high efficiency, low thermal dissipation and maximum reliability.
The USB and BT player with remote control allow audio contents reproduction and makes this amplifier easy to use for any user in installations such as hotels, shops, offices, home, and much more.
Highlights
Class-D
Product details
Key features
| Built-in 2x30W stereo Class D amplifier | |
| Short-circuit, Overheating, and Overloaded Protection | |
| Supports wireless Bluetooth 3.0 and USB/SD playing | |
| Supports Voice Recording and Digital Volume Control | |
| 1 AUX and 1MIC input, 1 AUX output for power extension | |
| Remote Controller for convenient use | |
| 12-24V DC Power Adapter (Included) | |
| Portable, Robust and Durable Aluminum housing |
Specifications
| LINE input sensitivity | 310mV |
| MIC input sensitivity | 10mV |
| Frequency response | 20-20kHz (±3dB) |
| Noise | 2mV (Output terminal) |
| Distortion | <1% |
| Rated voltage | 20V DC |
| Rated output power | 2×30W |
| Max power consumption | 90W |
| USB Connection | Type-B, Female |
| SD-Card | SD-Card Slot |
| USB / SD-Card Drive Format | FAT32 format – max 32GByte |
| Player File Formats | MP3 e streaming audio wireless BT |
| Recorder File Format | MP3 (44.1kHz/16bit @ 128Kbps) |
| Unit Size (WxDxH) | 180×163×55 mm |
| Package size (WxDxH) | 297×223×108 mm |
| Unit Weight | 0.82Kg (Without power adapter) |
| Gross weight | 1.5Kg |
