REPO-240A
Description
REPO-240 – Powerful. Versatile. Always in Control.
The REPO-240A is a 240W single-zone multi-purpose mixer amplifier built to deliver crystal-clear sound, rock-solid reliability, and the flexibility your installation demands.
With its 8-channel mixer at the core, the REPO-240A gives you seamless integration of multiple sources. It features 2 Mic/Line inputs ... Read more
REPO-240 – Powerful. Versatile. Always in Control.
The REPO-240A is a 240W single-zone multi-purpose mixer amplifier built to deliver crystal-clear sound, rock-solid reliability, and the flexibility your installation demands.
With its 8-channel mixer at the core, the REPO-240A gives you seamless integration of multiple sources. It features 2 Mic/Line inputs for microphones or balanced sources, plus 4 stereo line inputs for music players, media devices, or external processors – making it ideal for both speech and music applications.
Driving up to 240 watts of Class-D power, this amplifier ensures efficiency and clean performance across 70V, 100V, and low-impedance (4Ω) outputs, adapting easily to a wide range of system designs.
For paging and announcements, the REPO-240A includes a dedicated paging microphone with chime and voice-over function, so messages cut through the mix with clarity. Add flexibility with a line output, plus emergency input and 24V priority control output, ensuring critical announcements always take precedence.
Energy-conscious? The built-in auto-standby function reduces power consumption while keeping the system instantly ready.
From corporate facilities to retail stores, schools, and hospitality environments, the REPO-240A delivers powerful amplification, intuitive control, and versatile connectivity—all in a single professional package.
Read lessHighlights
Product details
| 8-Channel Mixer | |
| 2 Mic/Line Inputs with 2-Band EQ and 48V Phantom | |
| 4 Stereo Line Inputs with 2-Band EQ | |
| 240W Class-D Power Amplifiers | |
| 70V, 100V and 4ohm Outputs | |
| Paging Microphone with Chime and Mic/Line button | |
| Voice Over on Mic 1 and Paging Mic Input | |
| Emergency 0dB Input with Mute All and Voice over controls | |
| 24V Priority Control Out | |
| 80Hz Low-Cut Filter | |
| Stereo Preamp Out | |
| Auto-Standby Function |
| Power Supply | AC 170 V-240V 50Hz/60Hz (IEC) |
| Fuse | T3.15AL 250V |
| Power Output | 240W RMS |
| Amplifier Construction | Class D + Transformer Outputs |
| Inputs | 1x Emergency (Euroblock terminal), 1x Paging Mic, 1x Mic A (XLR/Jack), 1x Mic B (XLR/Jack), 4x RCA |
| Line Output (REC) | 1x RCA, 0dBV |
| Speaker Outputs | 70V/100V and 4Ω (Euroblock terminals) |
| Filter | Selectable 80Hz Low Cut (18 dB/oct) |
| Phantom Power | +48V (Mic A, Mic B) |
| THD | <0.7% @ 1kHz |
| Input Impedance | 1kΩ (Mic), 10kΩ (Line) |
| Frequency Response | 80 Hz - 20kHz (-3 dB) |
| Control Output | 24VDC Max 0.5A on Emergency Mute All and Paging contact closure |
| Product Size (W x D x H) | 433 x 185 x 90 mm / 17.04 x 7.28 x 3.54 in |
| Weight | 5.6 kg |
| Package Size (W x D x H) | 530 x 341 x 129 mm / 20.87 x 13.42 x 5.08 in |
| Package Weight | 13.7 kg |
