HCA-40 PLAY
Description
This power amplifier is designed for recessed wall mounting in all those small installations where music or other audio content is required, and a 70V or 100V line is not requested.
HCA-40 PLAY delivers 2x20W @ 4-16ohm in Class-D. This ensures high efficiency, low thermal dissipation and maximum stability.
BT connection makes this small amplifier the right p... Read more
This power amplifier is designed for recessed wall mounting in all those small installations where music or other audio content is required, and a 70V or 100V line is not requested.
HCA-40 PLAY delivers 2x20W @ 4-16ohm in Class-D. This ensures high efficiency, low thermal dissipation and maximum stability.
BT connection makes this small amplifier the right product for hotels, shops, home and much more.
Read lessHighlights
Product details
| 2x20W Mini Class-D Amplifier | |
| 4-16ohm Speaker Output | |
| BT & AUX Audio Inputs | |
| Compact, Sturdy, and Stylish Design | |
| Aluminum Housing for Efficient Heat Dissipation |
| Rated Power | 2×25W |
| Maximum power | 2×40W |
| Frequency Response | 20Hz~20kHz |
| Harmonic Distortion | <0.1% |
| S/N Ratio | 82dB |
| Static Power Consumption | 0.24W |
| Impedance | 4-16ohm |
| Input Level | 0dbV (0.775V) |
| Input Impedance | >10kohm |
| BT Receiving Distance | 10m |
| BT Standard | BT2.1+EDR |
| Operation Voltage | 100-240Vac / 50Hz |
| Unit Size (WxDxH) | 125×100×35 mm |
| Packing Size (WxDxH) | 135×110×45 mm |
| Net Weight | 0.35kg |
| Gross Weight | 0.33kg |
